Compact LED spotlight
High performance and reduced size
Fluid and silent movements, incredible brightness, 3D functions and frost, Evora-SP60 is the most powerful fixture in its class.
- Lyre compact Spot
- New engine
- Rotating gobos and prisms
More light
Its new 60 Watt LED provides a flow of nearly 2,000 Lux at 5 meters with an aperture of 15° and a temperature of 6200° K. The result is a wide beam, very visible and clearly defined.
Functions
The new Evora lyre-SP60 offers impressive brightness and essential functions in a compact body suitable for delivery as the installation.
SPECIFICATIONS:
Light source
- LED 60W
- Color temperature: 6500 ° K
- Life 100 000 hours (flow> 70% after 60,000 hours)
- Low temperature, low power consumption, can work for several hours without interruption
Colours
- 1 wheel with 8 dichroic colors + white
- Rainbow effect in both directions
Gobos
- 1 wheel 7 rotating and indexable gobos
- 7 internal programs accessible from the DMX
- Gobo shake function
- 3 and 4 metal dichroic
- Dimensions: Outer 27 mm - 22 mm Image
Effects
- 2 rotating prism: 3-facet and 3D effect with macros
- Frost filter for color spread over 30 °
- Focus ultra precise motorized
- Variable Strobe 1-13 flashes per second and random strobe
- Variable electronic dimmer from 0 to 100%
Controls
- Standard DMX-512
- 14 DMX channels:
1 - Colors
2 - rotating gobos
3 - Rotating gobo
4 - Speed of movement
5 - PAN
6 - TILT
7 - Prisms
8 - Indexing prisms
9 - Focus
10 - Shutter and Strobe
11 - Dimmer
12 - Reset and Internal Programs
13-16-bit PAN
14-16 bits TILT
- 7 internal programs accessible from the DMX
- Internal musical programs
- Automatic detection of DMX or Master / Slave
- Display to drop down to the assignment and the choice of different modes
Movements
- Pan and Tilt with 8 or 16 bit resolution
- Range: Pan 540 or 630 ° - 256 ° Tilt
- Variable speed from the menu or DMX
- Position Memory and automatic repositioning
Optical
- Beamwidth 15°
- Intensity of 1970 Lux at 5m
Other features
- Adjustable fan speed
- Bracket with hook 1/4 turn Omega
- Power consumption: 250W max.
- Power Supply: AC 100/230V - 50/60Hz
- Weight: 12.5 Kg
